Stator for Aprilia ETV1000 Caponord 2001–2007 | AP0295835

Stator for Aprilia ETV1000 Caponord 2001–2007 | AP0295835

$79.99
$79.99
Sale Sold out
Shipping calculated at checkout.

Product Overview

Restore reliable charging-system output with this 18-coil, 3-wire magneto stator, designed for compatible 2001–2007 Aprilia ETV 1000 Caponord / Capo Nord motorcycles.

Built as an aftermarket replacement for AP0295835, this stator features an approximately 115mm outer diameter and 54mm inner diameter.

A failing stator may contribute to symptoms such as a battery that does not remain charged, low charging voltage, intermittent electrical problems, or reduced AC output from one or more stator phases.

Product Compatibility

Make Model Engine Year Range OEM Reference
Aprilia ETV 1000 Caponord / Capo Nord 1000cc 2001–2007 AP0295835

Model References

  • Aprilia ETV 1000 Caponord
  • Aprilia ETV1000 Capo Nord
  • Aprilia Caponord 1000

OEM Cross-Reference Number

Aprilia: AP0295835

Aprilia parts references identify AP0295835 as the 12V 420W ignition/generator unit used in the ETV 1000 Capo Nord application.

When possible, compare the original component number as well as the stator dimensions and wiring before ordering.

Specifications

Specification Details
Product Type Magneto Stator / Generator Stator
Make Aprilia
Model ETV 1000 Caponord
Engine Size 1000cc
Listed Year Range 2001–2007
Number of Coils / Poles 18
Number of Wires 3
Stator Outer Diameter Approx. 115 mm / 4.53 in
Stator Inner Diameter Approx. 54 mm / 2.13 in
OEM Reference AP0295835
Replacement Type Aftermarket
Condition New

Key Features

  • 18-Coil Design: Matches compatible ETV1000 Caponord stator configurations using an 18-pole winding assembly.
  • 3-Wire Output: Designed for compatible three-phase charging-system connections.
  • 115mm Outer Diameter: Provides an important physical reference for comparison with the original stator.
  • 54mm Inner Diameter: Helps confirm the correct stator size before installation.
  • AP0295835 Reference: Cross-referenced with the compatible Aprilia generator/stator assembly.
View full details

Fitment FAQ

Will this part fit my specific model and year?

This stator is listed for 2001–2007 Aprilia ETV 1000 Caponord / Capo Nord motorcycles.

For the strongest fitment confirmation, compare the OEM reference, stator dimensions, coil count, wiring, connector, and mounting configuration with your original part.

Do I need to match the OEM part number?

Matching the original part number is recommended.

The listed replacement reference is:

AP0295835

Also verify:

18-coil configuration
3-wire output
Approx. 115mm outer diameter
Approx. 54mm inner diameter
Connector configuration
Mounting points

What models or situations does this part not fit?

Do not assume this stator fits:

Every Aprilia 1000cc motorcycle
Every Caponord generation
Applications using a different stator diameter
Stators with a different coil count
Different wiring or connector configurations
Motorcycles with incompatible mounting points

The original supplier listing states 2001–2009, but the verified ETV1000 Caponord application range used on this page is 2001–2007.

What should I check before ordering?

Confirm:

Aprilia ETV 1000 Caponord / Capo Nord
2001–2007 model year
AP0295835 reference where applicable
18 coils
3 wires
Approx. 115mm outer diameter
Approx. 54mm inner diameter
Mounting-hole locations
Wire exit position
Connector type and pin arrangement
Original stator appearance

Compare the product photos and measurements directly with the original stator before purchase.
