Magneto Stator Coil for Honda XR250R (1996-2004) | 31120-KCE-671
Magneto Stator Coil for Honda XR250R (1996-2004) | 31120-KCE-671
Couldn't load pickup availability
Product Overview
Restore your XR’s legendary reliability with the GOOFIT Magneto Stator. This "plug-and-play" replacement is engineered to match the factory 31120-KCE-671 unit exactly. Specifically designed for late-model XR250 and XR250R series, it provides the consistent electrical output required for easy starting and a powerful spark on the trail. Whether you're navigating technical single-track or high-speed desert runs, this stator ensures your ignition system remains powered and dependable.
Product Compatibility
| Make | Model | Years | OEM Part Number |
| Honda | XR250R | 1996–2004 | 31120-KCE-671 |
| Honda | XR250 | 1996–2004 | 31120-KCE-671 |
Specifications
| Feature | Details |
| Design | High-Output 8-Pole Configuration |
| Outer Diameter | 88mm (3.46") |
| Inner Diameter | 35mm (1.38") |
| Thickness | 18mm (0.71") |
| Heat Resistance | Up to 200°C |
| Materials | Grade-A Copper & Electro-Conducting Lamination |
Key Features
- High-Grade Thermal Protection: Built with highest-grade copper windings resistant to temperatures up to 200°C, preventing the common "melt-down" failures found in inferior aftermarket parts.
- Trail-Ready Durability: Specifically engineered with premium electro-conducting lamination materials to handle the intense heat and high-vibration environments typical of off-road riding.
- Consistent Spark Delivery: Provides a stable current to the ignition system, effectively reducing sputtering and backfiring while improving throttle response.
- Plug-and-Play Installation: Designed to match your original unit’s dimensions perfectly, allowing for a hassle-free installation with no wiring modifications required.
- Improved Heat Dissipation: Advanced core materials promote faster cooling, protecting the internal circuits against electrical failure during heavy-duty engine use.
Need help diagnosing stator problems or installation steps?
Read our complete guide on Honda XR250R stator symptoms and replacement (1996–2004) to learn how this part solves common no-spark and hard-starting issues.
Share
Fitment FAQ
Will this part fit my specific model and year?
This magneto stator is intended for Years; OEM Part Number; Honda; XR250R; 1996–2004; 31120-KCE-671. It is best matched to original part number(s) 1996-2004, 31120-KCE-671. Key physical/spec details from the product data include Outer Diameter: 88mm (3.46"), Inner Diameter: 35mm (1.38"), Thickness: 18mm (0.71"). Use the compatibility table and product photos together before ordering.
Do I need to match the OEM part number?
Yes. Match your original part number to 1996-2004, 31120-KCE-671 before purchase. For this magneto stator, also compare the OEM number, outer/inner diameter, core height or thickness, plug shape, wire count, mounting holes, pickup position, and rubber grommet style. This is especially important for Honda XR250R/KCE-671 models because similar model names can use different parts by year or trim.
What models or situations does this part not fit?
Do not order this magneto stator for machines outside the listed compatibility, or for units with different plug layouts, pickup-coil positions, wire counts, stator diameters, or charging/ignition configurations. If your original part number does not cross-reference with 1996-2004, 31120-KCE-671, treat the fitment as unconfirmed. Model years outside 1996–2004, 1996, 2004 should be verified separately. Do not rely only on the model name or engine size.
What should I check before ordering?
Before ordering, compare your original part with the photos and check the OEM number, outer/inner diameter, core height or thickness, plug shape, wire count, mounting holes, pickup position, and rubber grommet style. Confirm OEM/cross-reference number(s): 1996-2004, 31120-KCE-671. Recheck listed specs such as Outer Diameter: 88mm (3.46"), Inner Diameter: 35mm (1.38"), Thickness: 18mm (0.71"). If any connector, mounting point, size, or year detail is different, confirm fitment before installation.
