Magneto Stator for Kawasaki Bayou 220 (1996-2002) & 250 (2003-2011) | 21003-1287

Magneto Stator for Kawasaki Bayou 220 (1996-2002) & 250 (2003-2011) | 21003-1287

$54.99
$54.99
Sale Sold out
Shipping calculated at checkout.

Product Overview

Replacement magneto generator stator for selected Kawasaki Bayou 220 and Bayou 250 ATVs, designed to replace OEM 21003-1287.

Compatible applications include 1996–2002 KLF220 Bayou 220 and 2003–2011 KLF250 Bayou 250.

This stator measures approximately 93mm outer diameter and 35mm inner diameter. It uses an 18-pole configuration with a compatible 3-wire electrical connection.

Product Compatibility

Make Model Model Code Year Range OEM Reference
Kawasaki Bayou 220 KLF220 1996–2002 21003-1287
Kawasaki Bayou 250 KLF250 2003–2011 21003-1287

OEM Cross-Reference Numbers

Kawasaki OEM: 21003-1287

Specifications

Specification Details
Product Type Magneto / Generator Stator
Make Kawasaki
Models Bayou 220 / Bayou 250
Model Codes KLF220 / KLF250
OEM Reference 21003-1287
Number of Poles 18
Number of Wires 3
Connector Pins 3
Mounting Holes 3
Outer Diameter Approx. 93 mm / 3.66 in
Inner Diameter Approx. 35 mm / 1.38 in
Application ATV Charging System
Replacement Type Aftermarket
Condition New

Key Features

  • Bayou 220 / 250 Fitment: Designed for compatible KLF220 and KLF250 ATV charging systems.
  • OEM 21003-1287 Replacement: Provides a strong part-number reference for fitment confirmation.
  • 18-Pole Configuration: Matches the compatible generator stator design.
  • 93mm OD / 35mm ID: Key physical dimensions for comparison with the original unit.
  • 3-Wire Connection: Designed for compatible Kawasaki charging-system wiring.
