Magneto Stator for Kawasaki KX250F & KX450F | OEM 21003-0168

Magneto Stator for Kawasaki KX250F & KX450F | OEM 21003-0168

$33.99
$33.99
Sale Sold out
Shipping calculated at checkout.

Product Overview

Keep your Kawasaki KX-F running at peak performance with this high-efficiency 12-coil magneto stator. Engineered for high-revving motocross engines, it delivers stable voltage output for ignition and fuel injection systems—ensuring responsive throttle, reliable starts, and consistent power delivery on any terrain.

Built with high-purity copper windings and a rugged, heat-resistant housing, this stator is designed to withstand extreme vibration, dirt, and racing conditions.

Product Compatibility

Brand Model Sub-Model / Notes Year Range
Kawasaki KX250F KX250 / KX252 4-Stroke 2011–2020
Kawasaki KX450F KX450 4-Stroke 2009–2018
Kawasaki KX250 Fuel Injection Models 2011–2020
Kawasaki KX450 EFI Models 2009–2018

Specifications

Specification Details
OEM Reference 21003-0168, 21003-0147, 21003-0102, 21003-0082
Outer Diameter 89 mm (3.51")
Inner Diameter 36 mm (1.42")
Coil Count 12-Coil (High Output)
Material High-purity copper windings
Housing Impact & heat-resistant
Installation Type Direct replacement

Key Features

  • 12-coil high-output design for improved charging efficiency
  • Stable voltage supply for EFI and ignition systems
  • High-purity copper windings for better conductivity
  • Durable construction resists heat, vibration, and dirt
  • Direct-fit design for easy installation
View full details

Fitment FAQ

Will this part fit my specific model and year?

This magneto stator is intended for Kawasaki; KX250F; KX250 / KX252 4-Stroke; 2011–2020; KX450F; KX450 4-Stroke. It is best matched to original part number(s) 21003-0168, 21003-0147, 21003-0102, 21003-0082. Key physical/spec details from the product data include Outer Diameter: 89 mm (3.51"), Inner Diameter: 36 mm (1.42"), 89 mm. Use the compatibility table and product photos together before ordering.

Do I need to match the OEM part number?

Yes. Match your original part number to 21003-0168, 21003-0147, 21003-0102, 21003-0082 before purchase. For this magneto stator, also compare the OEM number, outer/inner diameter, core height or thickness, plug shape, wire count, mounting holes, pickup position, and rubber grommet style. This is especially important for Kawasaki KX250F/KX450F/KX250/KX252 models because similar model names can use different parts by year or trim.

What models or situations does this part not fit?

Do not order this magneto stator for machines outside the listed compatibility, or for units with different plug layouts, pickup-coil positions, wire counts, stator diameters, or charging/ignition configurations. If your original part number does not cross-reference with 21003-0168, 21003-0147, 21003-0102, 21003-0082, treat the fitment as unconfirmed. Model years outside 2011–2020, 2009–2018, 2011, 2020, 2009 should be verified separately. Do not rely only on the model name or engine size.

What should I check before ordering?

Before ordering, compare your original part with the photos and check the OEM number, outer/inner diameter, core height or thickness, plug shape, wire count, mounting holes, pickup position, and rubber grommet style. Confirm OEM/cross-reference number(s): 21003-0168, 21003-0147, 21003-0102, 21003-0082. Recheck listed specs such as Outer Diameter: 89 mm (3.51"), Inner Diameter: 36 mm (1.42"), 89 mm. If any connector, mounting point, size, or year detail is different, confirm fitment before installation.
