Magneto Stator for Toro TimeCutter Zero Turn Mowers | SS4225 SS5000 MX4275T
Magneto Stator for Toro TimeCutter Zero Turn Mowers | SS4225 SS5000 MX4275T
Couldn't load pickup availability
Heavy-Duty Magneto Stator for Toro TimeCutter Series Zero Turn Mowers
Keep your mower running at peak performance. This premium aftermarket Magneto Stator is a precision-engineered replacement for Toro TimeCutter Zero Turn Mowers equipped with the 2P77F engine. It provides the stable electrical output required for reliable ignition, electric PTO clutch engagement, and consistent battery charging during long mowing sessions.
Manufactured with high-purity copper coils and a high-grade aluminum base plate, this stator is built to survive the extreme vibration and thermal stress of residential and commercial mowing. The full copper-clad steel wire ensures a more stable spark and sensitive throttle response, bringing reliable power back to your machine.
Product Compatibility
- Toro TimeCutter SS Series: SS4225, SS5000
- Toro TimeCutter ZS Series: ZS4200T, ZS5000
- Toro TimeCutter MX Series: MX4275T, MX7075
- Toro TimeCutter SW Series: SW4200
- Engine Model: Specifically for the 2P77F engine platform.
Key Technical Specifications:
- Outer Diameter: 138mm (5.43")
- Inner Diameter: 70mm (2.76")
- Core Thickness: 10mm (0.39")
- Material: Copper windings with aluminum mounting plate
- Design: Direct OEM-style replacement
Why Choose This Stator?
- Enhanced Ignition Performance: Provides a more stable spark, which contributes to easier starting and more consistent engine power under load.
- Superior Build Quality: Engineered with higher power capacity to handle the electrical demands of modern zero-turn mowers, including electric blades and accessories.
- Direct Plug-and-Play Fit: Designed as a straightforward swap for the original factory unit, matching mounting points and wiring configurations exactly.
Share
Fitment FAQ
Will this part fit my specific model and year?
This magneto stator is intended for Toro TimeCutter SS Series: SS4225, SS5000; Toro TimeCutter ZS Series: ZS4200T, ZS5000; Toro TimeCutter MX Series: MX4275T, MX7075; Toro TimeCutter SW Series: SW4200; Engine Model: Specifically for the 2P77F engine platform.. Key physical/spec details from the product data include Outer Diameter: 138mm (5. 43"), Inner Diameter: 70mm (2. 76"), Core Thickness: 10mm (0. 39"). Use the compatibility table and product photos together before ordering.
Do I need to match the OEM part number?
Yes. If your original part has a stamped OEM or manufacturer number, match that number first before ordering. For this magneto stator, also compare the OEM number, outer/inner diameter, core height or thickness, plug shape, wire count, mounting holes, pickup position, and rubber grommet style. This is especially important for SS4225/SS5000/MX4275T/ZS4200T models because similar model names can use different parts by year or trim.
What models or situations does this part not fit?
Do not order this magneto stator for machines outside the listed compatibility, or for units with different plug layouts, pickup-coil positions, wire counts, stator diameters, or charging/ignition configurations. Do not rely only on the model name or engine size.
What should I check before ordering?
Before ordering, compare your original part with the photos and check the OEM number, outer/inner diameter, core height or thickness, plug shape, wire count, mounting holes, pickup position, and rubber grommet style. Recheck listed specs such as Outer Diameter: 138mm (5. 43"), Inner Diameter: 70mm (2. 76"), Core Thickness: 10mm (0. 39"). If any connector, mounting point, size, or year detail is different, confirm fitment before installation.
